MONOBLOC MULTIFUNCTION BRATT PAN
Bowl drain on bottom removable basin supplied as standard.
Thermostat for temperature regulation from 50°C to 300°C.
Heating ensured by armoured heating elements positioned outside the tank bottom.
IPX4 water protection rating.
With a modern and elegant design, the Proxy70 cooking range is designed for small, medium and large facilities.
Front control panel made of AISI304 stainless steel with Scotch Brite finish, the front profile is designed for easy cleaning.
Complete and fully configurable range. modules can be freely placed on the bases to create the composition to suit every need.
Stainless steel outer panel with Scotch Brite finish.
Installation in the compartment is quick and easy thanks to the rear technical compartment, prepared for the passage of gas/electrical/water connections.
Moulded tops for robustness, reliability and hygiene.
Supplied as standard with H80 mm feet for flat installations, facilitating the installation, connection and safe maintenance of equipment in compliance with regulations.Bowl drain on bottom removable basin supplied as standard.
Thermostat for temperature regulation from 50°C to 300°C.
Heating ensured by armoured heating elements positioned outside the tank bottom.
IPX4 water protection rating.
Jointing of the modules by means of a dedicated element (JC joint cover accessory) to prevent liquids and dirt from seeping in between the equipment.
Supplied as standard with h80 mm feet for flat installations, to facilitate installation, connection and safe maintenance of equipment in compliance with regulations.
IPX4 water protection rating.
CR1354519 - Standard
Data sheet
- Model
- 74EFBM
- Packaging width
- 850000
- Code
- CR1354519
- Width
- 400mm
- Commercial code
- 74EFBM
- Packaging length
- 450
- Material type
- ZPF
- Alimentazione
- ELETTRICA
- Definition
- 74EFBM MULTIPLA ELETTRICA M40 13 LT
- Electrical power
- 4.05Kw
- Depth
- 700mm
- Frequency
- 50/60 HzHz
- Height
- 870mm
- Power supply
- 380-415V 3N
- Volume
- 0,244m3
- IP grade
- IPX4
- Gross volume
- 0440
- Voltage
- 400
- Net weight
- 32.5Kg
- Packaging height
- 1150
- Gross weight
- 35Kg
- Production site
- BELLUNO
- Certified model
- 74EFB
- Product type
- STANDARD
- Company
- 0230
- Commercial Line
- PROXY70
Specific References
- mpn
- 74EFBM
